Yellow Jacket 93266 YJII Vacuum Pump 5 CFM

$31316

Brand: Yellow Jacket GTIN#: 686800932668 MPN#: 93266

62 in stock

FREE delivery over $99

Easy 30 day return (Domestic)

Easy International shipping

Need Help? Speak with our HVAC and tools experts. Call or text (786) 239-7444.

Description

The Yellow Jacket 93266 YJII Vacuum Pump 5 CFM is a compact, lightweight, portable and affordable pump for servicing small systems. It has a wide range of applications. The thermal protector in the motor guarantees the pump runs steadily and safely for long periods. It also has a high torque motor design for easy start-up and efficient operation, even in the harshest conditions. Have a quick flow rate and an ultimate deep vacuum.

The Yellow Jacket 93266 YJII Vacuum Pump 5 CFM includes some cool features. It has 5CFM 115V/50-60 Hz single phase. It also has an ultimate deep vacuum. Also, a quick flow rate. As well as a wide range of applications. Furthermore, a 1/4″ and 3/8″ SAE flare inlet connection allows hose fittings/sizes to be flexible. Moreover, it has a 3/4″ garden hose exhaust fitting with a removable cap for venting. It’s also lightweight and has a durable aluminum housing. Furthermore, it has an oversized 3/8″ oil drain for faster oil changes. One neat thing about this YJII Vacuum Pump 5 CFM is that it’s small and portable. Another good feature is its reliability; it runs steadily for long periods. Also, it has a thermal protector in the motor to guarantee that the pump runs steadily and safely. Furthermore, it has a high torque motor design for easy start-up and efficient operation even in the harshest conditions.

  • 5 CFM 115V/50-60 Hz single phase
  • Deep ultimate vacuum - pulls to 25 microns or better
  • Quick flow rate
  • Wide range of applications
  • 1/4” and 3/8” SAE flare inlet connections allow for flexibility of hose fittings/sizes
  • 3/4″ garden hose exhaust fitting with removable cap for venting
  • Oversized 3/8″ oil drain for faster oil changes
  • Lightweight, durable aluminum housing
  • Small and portable
  • Reliable - runs steadily for long periods
  • Thermal protector in motor
  • High torque motor design for easy start-up and efficiency
  • One year warranty
Free air displacement : 5 cfm
Voltage (single phase) : 120V (50-60HZ)
Ultimate vacuum : 25 microns
Number of stages : 2
Motor : 1/2 hp – 1725 rpm
Intake ports : 1/4″ and 3/8″ SAE
Oil capacity : 18 oz (532 ml)
Dimensions : 13″ x 5″ x 11″ (330mm x 127mm x 279mm)
Weight : 25.3 lbs (11.5 kg)
Power Source : Corded-electric
Made in : China
Does the YJII vacuum pump have 1/4” and 1/2” fittings?

It has a 1/4″ and 3/8″ port.

Does the Yellow Jacket 93266 vacuum pump make a lot of noise?

It is very quiet but powerful.

Will the yjii vacuum pump achieve 500 microns?

Yes, easily.

No product videos available.

  • (1) Yellow Jacket YJII Vacuum Pump 5 CFM - 93266
  • (1) Start up Bottle of Pump Oil
  • (1) Owner's Manual
